Precision Machinery Conveniently Mobile Roof Mounted Package Unit With Wheels

Product Details:

Place of Origin:	China
Brand Name:	Longer Leader
Certification:	ISO9001, CQC
Model Number:	LDPTU-15HP

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Export standard paper carton or wooden case
Delivery Time:	30 days
Payment Terms:	T/T
Supply Ability:	30~50 sets / Month

Contact Now

Detailed Product Description

Product Name:	Rooftop Unit	Installation:	Ceiling Hang/floor Installation
Air Flow:	5,000~10,000 M3/h	Place Of Origin:	China
Warranty:	1 Year	Cooling Capacity(kW):	20~50kw
Heating Capacity(kW):	Optical	Brand Name:	Longer Leader
Video:	Provided	After-sales Service Provided:	Online Support
Type:	Water Cooled Direct Expansion
Highlight:	mobile roof mounted package unit , mobile package unit on roof , precision machinery package unit on roof

Conveniently Mobile Rooftop Packaged Unit With Wheels Suitable For Precision Machinery

Quick Model Selection for Typical Units

Model	Air volume (CMH)	Cooling (KW)	Fan motor (KW)	Heating (KW)	Humidification (kg/h)	Unit noise(db(A))
LDPTU-03HP	1500	7.8	0.75	6	3	65
LDPTU-05HP	2500	13	1.5	6	5	65
LDPTU-07HP	3500	18	1.5	9	8	65
LDPTU-08HP	4000	20.8	2.2	12	8	65
LDPTU-10HP	5000	26	2.2	15	10	70
LDPTU-12HP	6000	31.2	3	18	10	70
LDPTU-15HP	7500	39	4	18	15	70
LDPTU-20HP	10000	52	5.5	24	15	72
LDPTU-25HP	12500	65	7.5	30	20	74
LDPTU-30HP	15000	78	7.5	36	25	74
LDPTU-36HP	18000	93.6	11	48	32	76
LDPTU-40HP	20000	104	11	54	32	78
LDPTU-50HP	25000	130	15	66	45	80
LDPTU-60HP	30000	156	15	72	45	80

Note:

Follow the standard quality condition JISB8616-1984;
Indoor air dry/wet bulb temperature (℃): 27℃DB/19.5℃WB;

Cooling water temperature: inlet water 30℃. The outlet water is 35℃, and the humidification

amount and electric heating amount are selected according to the actual working conditions.

Product Description

Longer Leader air handling unit (AHU) air flow range is from 1,000m3/h to 300,000m3/h. Available functional sections includes fresh and retuen air mixing section, cooling and heating coil section, filter, electric heating, humidifying, heat recovery, secondary air-return, fan and air diffuser section etc..

When you choose a rooftop heating and cooling system, you don't lose several square feet to cooling system installation. There's no concrete pad to pour, no landscaping disruption or cutting down the size of your outdoor living space! The unit sits atop the roof, taking up space you wouldn't otherwise use.

Are packaged units better than split one?

Efficiency - Packaged units are assembled in factories, which typically means they are more efficient than split system.
Easy installation - As packaged units are only one single units, they are easier and more versatile to install.

Robust structure

The surface of the unit is made of quality color sheet, 1.0mm and 1.5mm thickness, which can resist corrosion, scratch and ultraviolet radiation.

The panel has 2 thicknesses in 25mm and 50mm. Inside the panel, hermetically foamed polyurethane(no fluorine) with a density of 40kg/m3 is used as the heat insulating material.

100% Fresh Air AHU ( heating and cooling)

Precision Machinery Conveniently Mobile Roof Mounted Package Unit With Wheels 0

Mixing Air AHU (single cooling)

Precision Machinery Conveniently Mobile Roof Mounted Package Unit With Wheels 3

PCR labortory AHU

Application

Laborory, Data center, Workshop, Hospital, Pharmaceutical, Railway station, Subway, Airport,

Office, Hotel,Supermarket,Airport, Factory,Villa .

Longer Leader Advantages

Variable speed drive (VSD) technology, explosion proof and energy saving.
